Food & Beverage Rotary Flow Meter Fillers
Request More Information ›Pacific Packaging Machinery is an industry leader for rotary flow meter fillers specifically designed and optimized for free-flowing non-carbonated beverages and light to semi-viscous foods.
Popular product applications include:
- Ready-to-drink beverages
- Hot sauces
- BBQ Sauces
- Condiments Edible oils
Pacific rotary flow meter fillers are available with electromagnetic flow meters, commonly referred to as mag flow meters or Coriolis mass flow meters, commonly referred to as mass flow meters. Mag flow meters are ideal for conductive products that do not contain oils. Coriolis mass flow meters are ideal for non-conductive products and high-value products that require precise fill accuracy. These technologies, along with integrated product supply tanks and pumps and over 100 filling valve designs, have established Pacific as an industry leader for high-speed production environments where filling accuracy and reliable performance are a priority.
Rotary flow meter fillers for foods and beverages can be configured with one of four filling valve configurations including bottom-up, true top fill, below the neck or diving. Pacific rotary flow meter fillers for foods and beverages are offered in filler only, monobloc filler-capper, and tri-bloc rinse-fill-cap configurations. They are designed and built for hygienic product environments and stainless steel construction with NEMA 4X electrical enclosures are standard. Specialized models including explosion-proof designs are also offered.
Pacific applications experts and engineers work closely with customers to configure every filler to meet or exceed both product and production requirements.
Pacific's filling systems are designed and manufactured in Corona, CA.
Key Features & Benefits
- Size range - Containers from 8 oz. (236 mL) to 128 oz. (3.78 L)
- Speed range - Steady-state speeds from 30 cpm to up to 600 cpm
- Highly accurate, consistent filling - Fill volume accuracy + / - 0.3% to 0.5%
- No container, no fill - System detects missing containers and the relevant filling valve is not activated, saving valuable product
- Tool-less size changeovers - Size changeovers require no tools to complete
- Four fill nozzle configurations - Bottom-up, true top fill, below the neck top fill or diving nozzle
- Simple fill adjustments - Fill volume or weight adjustments for each filling station executed through the HMI; no mechanical adjustments required
- Integrated product pump – Filling system includes pump best suited to product characteristics which enhances ease of operation
- Push button turret raising system - One touch power raising system elevates filling turret to facilitate size changeovers and improve machine access
- Wash down design - NEMA 4X electrical enclosures and 316L stainless steel construction for all wetted parts are ideal for hygienic food environments
